7782-6
Impact Wrench
In stock
SKU 6010136
$597.00
With this high-quality air-powered impact wrench from Chicago Pneumatic you’ll be able to enjoy increased stability thanks to the extended length anvil and its D-handle.
Overview
Meet the impact wrench rom Chicago Pneumatic which has been designed to handle the toughest jobs – where large truck wheels meet recessed hubs. Equipped with an extended length anvil, this powerhouse reaches those tight spaces effortlessly. Powered by a high-efficiency motor and fortified with a durable clutch mechanism, it’s built to tackle the most demanding tasks.
Size matters, and that’s why this tool comes with a purposeful D-handle, crafted for a two-handed grip. Aligning your hands directly with the tool’s body ensures total control and optimal pressure application. This strategic design provides the extra leverage you need to perform your job with precision and efficiency. Get ready to enhance your performance with this robust solution from Chicago Pneumatic!
Features
- 1" straight impact wrench with 6" extended anvil
- 1920 ft.lbs - 2600 Nm of maximum torque in reverse
- Pinless closed reinforced rocking dog impact mechanism
- Dual socket retention, hole and friction ring
- Ergonomic side handle
- Full teasing trigger
- Regulator with integrated forward/reverse with 3-position power settings in both directions
Specs
| Actual air consumption | 19.2 l/s / 40.7 cfm |
|---|---|
| Air inlet thread size | 1/2 " |
| Average air consumption | 4.8 l/s / 10 cfm |
| Blows per minute | 500 |
| Bolt size | M32 mm |
| Box dimensions | 670*245*130 mm / 26,35*9,6*5,11 " |
| Free speed | 5200 rpm |
| Length | 520 mm / 20.4 " |
| Maximum Torque (reverse) | 2600 Nm / 1920 ft.lbs |
| Min. hose size | 13 mm / 1/2 " |
| Net weight | 11.6 kg / 25.55 lb |
| Over carton | 670*245*130 mm / 26,35*9,6*5,11 " |
| Power/weight ratio | 257.4 Nm/kg / 86.5 ft.lb/lb |
| Sound Power | 111 db(A) |
| Sound pressure | 100 db(A) |
| Sound uncertainty | 3 db(A) |
| Square drive | 1 " |
| Vibration | 7.8 m/s² |
| Vibration ISO | ISO-28927-2 |
| Vibration uncertainty (K) | 1.8 m/s² |
| Working Torque Range (fwd) | 500 - 2000 Nm / 370 - 1475 ft.lbs |
