R103V83
10hp, 3 Phase, 208-230V, Enclosed Rotary Screw Compressor, 40CFM@150PSI
In stock
SKU 6010283
$8,301.00
This Industrial Gold 10HP Rotary Screw Air Compressor/Oil Cooler delivers 40CFM at 150PSI.
Overview
The R103V83 from Industrial Gold is a top-of-the-line air compressor which features an 80-gallon tank. This rotary screw compressor features an air and oil cooler as well as a spin-on separator. Industrial Gold has got you covered whenever you need a high-quality air compressor.
Features
- Air compressor part with 40 CFM at 150 PSI
- Features an 80 gal. vertical 200 PSI ASME/CRN air receiver tank
- Rotary screw compressor with TEFC drive motor, spin-on separator, and spin-on oil filter
- 2 pc. Tank and top plate
- Features an air and oil cooler
- Full ring base platform tank
Specs
| SKU# | 6010283 |
|---|---|
| Model | R103V83 |
| Shipping Weight | 600 lb. |
| Product Length | 38" |
| Airflow Volume | 40 CFM at 150PSI |
| Air Outlet Size | 34" |
| Application/Use | Agriculture, Oil and Gas, Automotive, Equipment Maintenance, Control Air |
| Compressor Type | Vertical |
| Country of Orgin | Made in USA |
| Drain System | Manual |
| Drive Type | Electric |
| Lubrication Type | Oil |
| Maximum Operating Pressure | 150 PSI |
| Number of Power Speeds | 1 |
| Portable or Stationary | Stationary |
| Power Type | Electric |
| Power Height | 78" |
| Power Width | 24" |
| Pump Material | Cast Iron/Steel |
| Running Horsepower | 10 HP |
| Tank Capacity | 80-Gal. |
| Tank Orientation | Vertical |
| Voltage | 208-230V 3 Phase |
